SCOPEX PG6 GOLD ANALYZER
The SCOPEX PG6 Gold Analyzer is a high-performance instrument designed for precise determination of gold carat and purity. Its user-friendly touchscreen interface ensures fast and accurate analysis, making it ideal for retail and hallmarking centers.
Advanced Portable X-Ray Fluorescence Analyzer for Precious Metal Testing
Compact. Accurate. Efficient.
The NEO ScopeX XRF Analyzer is a state-of-the-art portable solution for fast, non-destructive testing of gold, silver, and other precious metals. Designed for jewelers, hallmarking centers, refineries, and labs, it delivers lab-grade accuracy in a desktop-sized unit.
12.1" Touch Display • Wireless & USB Connectivity • Integrated Camera & PC
Product Introduction
Accuracy
High-precision multi-element analysis
Speed
Delivers chemistry and karat results in seconds
Portability
Weighs under 50 kg; compact and portable
Advantage
Non-Destructive Testing
Maintain sample integrity while performing high-accuracy tests
Real-Time Camera View
Built-in HD camera allows precise sample alignment
Wireless Connectivity
WiFi + USB interfaces for flexible data transfer and operation
Fast Certification Output
Quick results and report generation through integrated software
Compact Package
Desktop-friendly with minimal space requirement
Benefits
Easy one-push operation
3–60 second analysis time
Touchscreen PC interface — no external system needed
Live camera feed for customer transparency
Free lifetime software upgrades
Minimal setup; ideal for showrooms and mobile labs
Key Details:
High-Performance Gold Analyzer
Precise Carat and Purity Determination
Suitable for Retail and Hallmarking
Recommend users
Gold Testing Labs
Hallmarking Centers
Jewelry Makers
Government Labs
Tunch Testing Labs
Refiners & Smelters
Pawn Brokers
NBFCs & Banks
Research Institutes
Technical Specifications
Fiber Laser | N1 Series XRF Precious Metal Tester |
|---|---|
Sample Chamber Size | 320 × 480 × 130 mm (W × D × H) |
Size of Host Machine | 330 × 580 × 360 mm (W × D × H) |
Weight | 38.6 kg |
Display Screen | 11.6-inch large capacitive touch screen |
Detection Range | Al – U (Aluminum to Uranium) |
Accuracy | ±0.03% (999 gold) |
Analysis Range | 1 ppm to 99.99% |
Test Object | Solid, Liquid, Powder |
Tube Window | Glass window |
Optical Structure | Vertical |
Detector | Si-PIN detector |
Collimator | Equipped with 2.5 mm collimator to reduce background noise, improve resolution and accuracy |
Camera | The built-in 5-megapixel HD CMOS color camera not only provides users with intuitive sample positioning and image recording functions, but also ensures that the X-ray accurately illuminates the target area, thereby improving operational accuracy |
Language | Multi-language support (including Chinese and English) |
Power Supply | AC 220V ± 5V, 50Hz (subject to change in different regions) |
Algorithm | Adopts curve calibration method and fundamental parameter(FP) method to remove background difference, reduce error and improve test accuracy |
One-Click Test Button | “Place the sample → close the top cover → one-click test → view results” — simplified operation for non-technical users |
Data Printing | Supports Bluetooth printer |
